100G QSFP28
EQNET’s 100G QSFP28 optical transceivers in the QSFP ( Quad Small Form-Factor Pluggable ) form factor offer customers a wide variety of high-density and low-power 100 Gigabit Ethernet connectivity options for data centers, high-performance computing networks, enterprise core and distribution layers, and service provider applications. 100G QSFP28 optical module usually uses a 4-channel optical signal and a 4-channel NRZ electrical signal. EQNET provides a wide range of QSFP28 series products, including SR4 100m over multimode fiber, PSM4 for 500M transmission over single-mode fiber, and CWDM4, LR4, ER4, and ZR4, which reach up to 2KM, 10KM, 40KM, 80km, or even 100km over single-mode fiber. EQNET could also provide 100G SR BIDI and 100G SWDM4, which build links with LC connectors over multimode fiber.
| Form Factor | QSFP28 |
|---|---|
| Data Rate | 100G/ps, 112G/ps (OTU4), 40G I 100G/ps |
| Distance | 100km, 100M, 10KM, 20km, 2KM, 30~40KM, 40KM, 500M, 70km, 80KM |
| Wavelength | 1310nm, 2 CH DWDM, 850/880/910/940nm, 850nm, 850nm/910nm, CWDM4, L4 Tx 1280/ L4 Rx 1310nm, L4 Tx 1310/ L4 Rx 1280nm, LWDM4 |
| Operation Temperature | 0 to 70°C (32 to 158°F) |
| Connector | Dual CS, Duplex LC, MTP/MPO-12, Simplex LC |
| Voltage | 3.3V |
| Cable Type | MMF, SMF |
| DDM | Yes |
| Transmitter Type | 4x DFB, 850mm VCSEL, 850nm VCSEL, CWDM DFB, EML, LAN WDM DFB, LAN WDM EML, LAN WDM Laser |
| Receiver Type | APD, PIN, PIN with SOA |
| TX Power | -0.2~+6.6dBm, -1.0~+4.0dBm, -2.9~+4.5dBm, -2.9~+6.5dBm, -4.3~+4.5dBm, -5.5~+2.0dBm, -6.2~+4.0dBm, -6.5~+2.5dBm, -7.1~+4.2dBm, -8.4~+2.4dBm, +4.0~+8.0dBm |
| Receiver Sensitivity | < -10.2dBm, < -10.3dBm, < -10.6dBm, < -11.5dBm, < -12.5dBm, < -12dBm, < -20.5dBm, < -20.9dBm, < -20dBm, < -30dBm, < -7.6dBm, <Â -9.4dBm |
| Protocols | MSA Compliant, QSFP28 MSA |
| Warranty | 3 years |
