25G SFP28
EQNET’s 25GBASE SFP28 (Small Form-Factor Pluggable) product family offers customers a wide variety of high-density and low-power 25 Gigabit Ethernet connectivity options for data center and high-performance computing network applications. The 25G SFP28 optical transceivers include 850nm, 100m over multimode fiber, and 10km, 20km LR, 30km, 40km ER, and 80km ZR over single-mode fibers. We also provide 25G BIDI SFP28 optical modules that reach up to 10km, 20km, and 40km over single-fiber connections. 25G SFP28 single channel CWDM and DWDM 10-20km optical modules are also more and more applied to ethernet networking upgrading from 10G to 25G. 25G SFP28 adopt LC interface and compatible with IEEE802.3by, IEEE802.3cc, SFF-8472 and other standards.
| Form Factor | SFP28 |
|---|---|
| Data Rate | 25G/ps |
| Distance | 100M, 10KM, 15KM, 20km, 2KM, 300M, 30km, 40KM, 80KM |
| Wavelength | 1300nm, 1310nm, 850nm, C-Band DWDM CHxx, CWDM xxxxnm 1270nm~1610nm, M-Band DWDM CHxx, O-Band DWDM CHxx, Tx 1270nm / Rx 1310nm, Tx 1270nm / Rx 1330nm, Tx 1310nm / Rx 1270nm, Tx 1330nm / Rx 1270nm |
| Operation Temperature | -40 to 85°C (-40 to 185°F), 0 to 70°C (32 to 158°F) |
| Connector | Duplex LC, Simplex LC |
| Voltage | 3.3V |
| Cable Type | MMF, SMF |
| DDM | Yes |
| Transmitter Type | 1270nm DFB, 1300nm EML, 1310nm DFB, 1310nm DML, 1310nm EML, 1330nm DFB, 1330nm DML, CWDM EML, DWDM EML, EML Laser, MWDM EML, VCSEL 850nm |
| Receiver Type | APD, PIN |
| TX Power | -1.0~+6.0dBm, -1~+6.0dBm, -3.0~+6dBm, -4.0~+4dBm, -4.5~+2.5dBm, -6.0~+2.4dBm, -8.4~+2.4dBm, .-13.0~+2.0dBm, .-7.0~+2.0dBm, 0~+5.0dBm, 0~+6.0dBm, 0~+6dBm |
| Receiver Sensitivity | < -10.3dBm, < -11.4dBm, < -11.9dBm, < -13.3dBm, < -14.0dBm, < -14dBm, < -15dBm, < -17.5dBm, < -18dBm, < -19.0dBm, < -30.0dBm |
| Protocols | MSA Compliant |
| Warranty | 3 years |
