50G QSFP28
EQNET’s 50G QSFP28 transceiver modules are high-performance, cost-effective modules for 50Gigabit Ethernet links over single-mode fiber. They adopt QSFP28 form factors and LC connectors and are compliant with the QSFP28 MSA, IEEE 802.3cd. EQNET’s 50G QSFP28 including LR 10km, ER 40km and ZR2 80km over single-mode fiber could also offer 50G QSFP28 BIDI optical transceivers reach up to 10km and 40km. The 50G QSFP28 product line is designed for 5G mid-haul and back-haul applications.
| Form Factor | QSFP28 |
|---|---|
| Data Rate | 50G/ps |
| Distance | 10KM, 40KM, 80KM |
| Wavelength | 1310nm, LWDM2, Tx 1270nm / Rx 1330nm, Tx 1295nm / Rx 1309nm, Tx 1309nm / Rx 1295nm, Tx 1330nm / Rx 1270nm |
| Operation Temperature | 0 to 70°C (32 to 158°F) |
| Connector | Duplex LC, Simplex LC |
| Voltage | 3.3V |
| Cable Type | SMF |
| DDM | No |
| Transmitter Type | 1310nm DML, LAN WDM EML, LAN-WDM |
| Receiver Type | APD, PIN, PIN with SOA |
| TX Power | -4.5~4.2dBm, +0.4~+6.63dBm, +2~+6.5dBm, 0.4~6.6dBm |
| Receiver Sensitivity | < -26.4dBm, <-10.8dBm, <-15.1dBm, <-17.6dBm |
| Protocols | MSA Compliant |
| Warranty | 3 years |
