50G SFP56
EQNET’s 50G SFP56 optical transceivers offer customers a wide variety of high-density and low-power 50G and 25G Gigabit Ethernet connectivity options for data center and high-performance computing network applications. They are using 50Gb/s PAM4 channels to achieve a 50GE connectivity suitable for switch interconnects. EQNET could offer 50G SFP56 products including SR 100m over multi-mode fiber, 2km FR, 10km, 20km LR, and 40km ER over single-mode fiber. It is compliant with IEEE 802.3cc, IEEE 802.3cn, IEEE 802.3cd, IEEE 802.3by, and CPRI V7.0.
| Form Factor | SFP56 |
|---|---|
| Data Rate | 50G/ps |
| Distance | 100M, 10KM, 20km, 2KM, 40KM |
| Wavelength | 1310nm, 850nm |
| Operation Temperature | -40 to 85°C (-40 to 185°F), 0 to 70°C (32 to 158°F) |
| Connector | Duplex LC |
| Voltage | 3.3V |
| Cable Type | MMF, SMF |
| DDM | No |
| Transmitter Type | 1310nm DFB, 1310nm EML, VCSEL 850nm |
| Receiver Type | PIN |
| TX Power | -4.5~4.2dBm, -6.5~4dBm, .+0.3~+6.5dBm, 0.4~6.6dBm |
| Receiver Sensitivity | <-10.8dBm, <-17.6dBm, <-8.4dBm |
| Protocols | MSA Compliant |
| Warranty | 3 years |
